Machine Vision inspects a wide range of objects & scenes

Various utilities and information are provided on a

No-fee/Open-source basis.

Instead, you are invited to make a donation to

Centre for the Study of the Bible & Violence

Bristol Baptist College, Bristol, England, UK.

Getting Started (No fee)

Application Advisory Service

I am a retired professor with over 45 years of experience, devising Machine Vision systems for industrial and other applications. Click on the dragon to see how I can help

Lecture Courses (Live via Zoom)

The following courses are available

   • Basics of Image Processing

   • Interactive Image Processing

   • Analysing a new application for Machine Vision

Open source e-book: "Machines Can See ...but not as we do"

Chapter 1.jpg

Chapter 1: Vision in Nature

There are more than 40 different paradigms for  vision in nature, all very different from human vision. For aeons, animals with simple vision systems have been successful in meeting the demands of life. Machine Vision engineers need not strive to emulate all of the subtleties and quirks of human vision when a simpler approach will suffice.

Chapter 2.jpg

Chapter 2: A New Vision

Machine Vision systems are being used widely now, to inspect and measure industrial artifacts as they are being made. Visual machines can perform certain tasks much faster than a human being, tirelessly and consistently while being more reliable and more precise.

Download & view two pages using a PDF reader.

Chapter 3.jpg

Chapter 3: Images As Numbers

Monochrome (grey-scale) images can be represented by an array (table) of numbers. Colour images require three such arrays. A binary image is a special type of grey-scale image containing only black and white. More efficient methods of representing edges in binary images exist and can often increase processing speed.

Download & view two pages using a PDF reader.

Chapter 4.jpg

Chapter 4: 256 Shades of Grey (Text)

The simplest image processing operators convert one image into another. Examples: blurring, highlighting edges, enhancing contrast, pseudo-colouring, detecting corners, spots and cracks. Combining two images; and measuring image statistics are also described.

Chapter 4.jpg

Chapter 4: Figures

To view the text and figures simultaneously, download and save both files. Then, display them, side-by-side, in separate windows, using a PDF reader.

This was found to be a convenient way to display a document containing a large number of full-page figures accompanied by only a small amount of text.

Chapter 5.png

Chapter 5: Seeing Things in Black & White

                             (Text)

Counting, measuring size, shape, position and orientation of blob-like objects are essential for most Machine Vision applications. Blobs can be reduced to simple geometric figures: rectangles,  circles, ellipses, convex polygons, "skeletons", etc and a variety of blob shape measurements is possible.

Chapter 5.png

Chapter 5: Figures

To view the text and figures simultaneously, download and save both files. Then, display them, side-by-side, in separate windows, using a PDF reader.



This was found to be a convenient way to display a document containing a large number of full-page figures accompanied by only a small amount of text.

Chapter 6.jpg

Chapter 6: Adding a Bit of Colour (Text)

The prime requirement for industrial vision systems is almost always verification, rather than recognition. Colours have to be learned. This applies to standard named colours (red, blue, yellow, etc)  as well as those found on industrial artifacts, packaging, food products (e.g cakes, pies, etc) and natural materials (minerals, fruit, vegetables, etc).

Chapter 6.jpg

Chapter 6: Figures

To view the text and figures simultaneously, download and save both files. Then, display them, side-by-side, in separate windows, using a PDF reader.

This was found to be a convenient way to display a document containing a large number of full-page figures accompanied by only a small amount of text.

Chapter 7.jpg

Chapter 7: Applications

Applications are illustrated for

Glass & clear plastics, Natural products, Food processing,

X-ray imaging, Thermal imaging, Manufacturing,

Sport & Leisure, Privacy & security,

Fabrics & printed patterns

More Resources (Open Source)

Dragon 12.jpg

Additional Illustrations

No attempt has been made to organise these illustrations, or integrate them with the rest of the book.

My aim was to produce a range of teaching resources that I hope will assist, inspire, or intrigue & entertain.

​Slow operation: Clicking on the dragon will dowload a large PDF file. To display it, down-load it and use a PDF reader to view two pages side-by-side.

Dragon 14.jpg

Machine Vision Questionnaire



The MVQ can assist in formalising the requirements and specification for a inspection system. It covers a wide wide variety of technical, operational and managerial issues that should be considered, enabling an engineer to assess the  feasibility of a proposed application and the likely benefits.

Dragon 15.jpg

Proverbs



Attempting to encapsulate the "wisdom" of good systems thinking for Machine Vision, in a collection of one-liners.



Emeritus Professor Bruce Batchelor,

BSc, PhD, DSc, FSPIE, FSME, FRSA



Email: bgbatchelor@talktalk.net

Location: Wales, UK

© Bruce Batchelor, 2021-2024

To the glory of God and in memory of my dear wife Eleanor.
